Περιγραφή
Design
Product colour: Black
Housing material: Metal
Power
Power consumption (max): 96 W
Power source: DC
Input current: 1.81 A
Power supply included: Yes
DC input voltage: 53 V
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): -10 - 55 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Width: 240 mm
Depth: 105 mm
Weight: 650 g
Height: 28 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3bt
10G support: No
Packaging data
Package width: 279 mm
Package height: 89 mm
Package weight: 1.4 kg
Package depth: 239 mm
Certificates
Compliance certificates: Federal Communications Commission (FCC), CE
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
SFP module slots quantity: 1
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
Forwarding rate: 4.17 Mpps
Packet buffer memory: 0.5 MB
MAC address table: 8000 entries
Switching capacity: 5.6 Gbit/s
Jumbo frames: 9000
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 8
Total Power over Ethernet (PoE) budget: 96 W
Warranty: Manufacturer warranty 24 months
