Περιγραφή
Description
The USW-16-POE is a UniFi 16x Gigabit ports, 2 SFP Ports, 8x POE+ IEEE 802.3af/at ports rack cabinet.
Features
(8) GbE PoE+, (8) GbE ports
(2) 1G SFP ports
42W total PoE availability
Fanless, silent cooling
Specifications
Mechanical
Dimensions
424.4 x 200 x 43.7 mm (16.71 x 7.87 x 1.72?)
Weight
With Rackmount Brackets
2.80 kg (6.17 lb)
2.89 kg (6.37 lb)
Interfaces
NetworkingManagement
(16) 10/100/1000 RJ45 Ports
(2) 1G SFP Ethernet Ports
Ethernet In-Band
Total Non-Blocking Throughput
18 Gbps
Switching Capacity
36 Gbps
Forwarding Rate
26.78 Mpps
Power Method
100-240VAC/50-60 Hz, Universal Input
Power Supply
AC/DC, Internal, 60W
Supported Voltage Range
100 to 240VAC
Max. Power Consumption (Excluding PoE Output)
18W
LEDs
RJ45 Data Ports
SFP Data Ports
PoE; Speed/Link/Activity
Link/Activity
ESD/EMP Protection
Air: ± 16 kV, Contact: ± 12 kV
Shock and Vibration
ETSI300-019-1.4 Standard
Operating Temperature
-5 to 40° C (23 to 104° F)
Operating Humidity
10 to 90% Noncondensing
Certifications
CE, FCC, IC
PoE
Total Available PoE
42W
PoE Interfaces
Ports 1-8
POE+ IEEE 802.3af/at (pins 1, 2+; 3, 6-)
Max. PoE Wattage per Port by PSE
802.3at
32W
Voltage Range 802.3af Mode
44-57V
Voltage Range 802.3at Mode
50-57V
