Περιγραφή
? 5x 100/1000/2500 Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX
? IEEE 802.3x flow control and 4 Mbit packet buffer prevents packet loss
? Power saving strategy saves power consumption when ports are idle
? IGMP for high-efficienct multi-cast transmitting
? Loop detection blocks loop automatically, improving reliability
? Desktop and wall-mounting
Model
HS105
Standard configurati
5x 100/1000/2500 Mbps RJ-45 Ethernet Ports
Switching Capacity
25 Gbps
Throughput
18.6 Mpps
Packet Buffer
4 Mbit
MAC Address
8K
Jumbo Frame
15 KB
Transfer Mode
Store and forward
MTBF
100000 hour
Network protocol
IEEE802.3u (100Base-TX)
IEEE802.3ab (1000Base-T)
IEEE802.3bz (2.5GBase-T)
IEEE802.3x (Flow control)
Network Medium
100Base-TX : Cat5 or higher (<=100m)
1000Base-TX : Cat5 or higher (<=100m)
2.5GBASE-T: Cat 5e (<=50m), Cat 6 or higher (<=100m)
Working Environment
Working Temperature:-0~40°C
Storage Temperature:-40~70°C
Working Humidity :0%~100%, non-condensing
Storage Temperature:5%~90%, non-condensing
Structure Size
Product Size:119x85x28 mm (4.69x3.35x1.1 inches)
Installation
Desktop, Wall-Mounting
Power Saving
Saves power consumption when ports are idle
Power Voltage
Adpter Input Voltage :AC 100-240 V
Switch Input Voltage::DC 12V 1A
Power Consumption
Max: 10.5W
Idle: 4.7W
ESD Protection
±4KV contact discharge and ±8KV air discharge
Grounding Point
Grounding Point
Package Content
Switch
Power Adapter
Quick Installation Guide
Mounting Kit
PORTS
5
ΤΑΧΥΤΗΤΑ
2.5 Gbps
ΤΥΠΟΣ SWITCH
DESKTOP
