Περιγραφή
Design
LED indicators: Power, Activity, Link, System, Speed
Product colour: Black
Rack mounting: No
Security
DHCP features: DHCP client
DoS attack prevention: Yes
IGMP snooping: Yes
Password protection: Yes
Loop protection: Yes
Operational conditions
Operating relative humidity (H-H): 0 - 90%
Non-operating altitude: 0 - 3000 m
Storage temperature (T-T): -20 - 70 °C
Operating temperature (T-T): 0 - 50 °C
Operating altitude: 0 - 3000 m
Storage relative humidity (H-H): 0 - 95%
Management features
Virtual Cable Test (VCT): Yes
Switch type: Managed
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 100 mm
Height: 27 mm
Weight: 250 g
Width: 94 mm
Network
Virtual LAN features: Tagged VLAN, Port-based VLAN
Number of VLANs: 64
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.3u, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p
Flow control support: Yes
Link aggregation: No
Port mirroring: Yes
Rate limiting: Yes
VLAN support: Yes
Performance
Buffer size: 128 KB
Mean time between failures (MTBF): 2531294 h
Packaging data
Package depth: 237 mm
Package weight: 600 g
Package height: 61 mm
Package width: 153 mm
Package type: Box
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 5
Logistics data
Products per master (outer) case: 15 pc(s)
Master (outer) case gross weight: 10.2 kg
Harmonized System (HS) code: 85176990
Master (outer) case width: 344 mm
Master (outer) case height: 280 mm
Master (outer) case length: 497 mm
Data transmission
MAC address table: 8000 entries
Switching capacity: 10 Gbit/s
Jumbo frames: 9000
Store-and-forward: Yes
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Warranty: Manufacturer warranty 60 months
