Chieftec power supply unit 550 W 20+4 pin ATX PS/2 Black - (GDP-550C)

Technical details
Sustainability certificates: RoHS

Design
Fan diameter: 14 cm
Product colour: Black

Power
AC input frequency: 47 - 63 Hz
Max output current (+12V1): 45 A
Power protection features: Short circuit, Over voltage, Under voltage, Over current, Overload, Overheating
Input current: 4 A
Total power: 550 W
Max output current (+5V): 20 A
Combined power (+3.3V): 110 W
Power Factor Correction (PFC) type: Active
Combined power (+5V): 110 W
AC input voltage: 200 - 240 V
Max output current (-12V): 0.3 A
Max output current (+5Vsb): 2.5 A
Max output current (+3.3V): 20 A

Weight & dimensions
Width: 150 mm
Depth: 160 mm
Height: 87 mm

Performance
ATX version: 2.3
Purpose: PC
Power supply unit (PSU) form factor: PS/2

Ports & interfaces
Floppy drive power connector: 1
Cabling type: Semi-Modular
Number of SATA power connectors: 6
Peripheral (Molex) power connectors (4-pin): 3
PCI Express power connectors (6+2 pin): 2
Motherboard power connector: 20+4 pin ATX
CPU power connector (4+4 pin): Yes

Logistics data
Harmonized System (HS) code: 84733020

Safety warning
Hazard pictogram(s): GHS09: Environmental hazard, GHS07: Harmful, GHS02: Flammable


Warranty: guarantee 24 months
