Περιγραφή
Design
Housing material: Aluminium, Iron
Rack mounting: No
Number of fans: 1 fan(s)
Wall mountable: Yes
DIN rail mounting: No
Reset button: Yes
Product colour: Grey
LED indicators: Yes
Stackable: No
Redundant fans support: Yes
Power
Power consumption (max): 20.06 W
Power supply included: Yes
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power source: AC
Security
IGMP snooping: Yes
DHCP features: DHCP client
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 10 - 90%
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Management features
Switch layer: L2
Web-based management: Yes
Switch type: Managed
MIB support: Y
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 250 mm
Depth: 104 mm
Weight: 783 g
Height: 27 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3an, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3ae
Ethernet LAN data rates: 10,100,1000,2500,10000 Mbit/s
Auto MDI/MDI-X: Yes
Port mirroring: Yes
Flow control support: Yes
Broadcast storm control: Yes
10G support: Yes
Link aggregation: Yes
Full duplex: Yes
VLAN support: Yes
Ports & interfaces
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
SFP+ module slots quantity: 1
Basic switching RJ-45 Ethernet ports quantity: 11
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Jumbo frames support: Yes
Jumbo frames: 12000
MAC address table: 16000 entries
Forwarding rate: 71.42 Mpps
Switching capacity: 96 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Warranty: Manufacturer warranty 24 months
