Περιγραφή
Design
Stackable: No
Form factor: Desktop
Product colour: Grey
Rack mounting: No
LED indicators: Yes
Power
Power source: AC
Power consumption (max): 4.165 W
Power supply included: Yes
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Security
Password protection: Yes
DHCP features: DHCP client
IGMP snooping: Yes
Queue scheduling algorithms: Weighted Round Robin (WRR)
Operational conditions
Heat dissipation: 14.212 BTU/h
Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 10 - 95%
Storage relative humidity (H-H): 10 - 95%
Storage temperature (T-T): -40 - 70 °C
Management features
Switch type: Managed
Switch layer: L2
Web-based management: Yes
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 338 g
Depth: 85 mm
Height: 26 mm
Width: 193 mm
Network
Broadcast storm control: Yes
Virtual LAN features: Port-based VLAN
10G support: No
Flow control support: Yes
Port mirroring: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-T, 1000BASE-T
VLAN support: Yes
Networking standards: IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad, IEEE 802.3az
Full duplex: Yes
Performance
Fanless: Yes
Mean time between failures (MTBF): 909732 h
Ports & interfaces
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 8
Data transmission
Jumbo frames: 15
Jumbo frames support: Yes
Forwarding rate: 14.88 Mpps
Packet buffer memory: 0.192 MB
MAC address table: 4000 entries
Switching capacity: 20 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Number of multicast groups filtered: 128
Multicast support: Yes
Warranty: Lifetime warranty
