Περιγραφή
Design
LED indicators: Yes
International Protection (IP) code: IP65
Device type: 5G LTE outdoor unit
Product colour: White
Power
Power source type: AC
Operational conditions
Operating temperature (T-T): -40 - 60 °C
Weight & dimensions
Depth: 31.2 mm
Weight: 500 g
Height: 189.6 mm
Width: 108.8 mm
Performance
Processor model: SDX62
Built-in processor: Yes
Power over Ethernet (PoE): Yes
Packaging content
Cables included: LAN (RJ-45)
Set contents: Installation kit, Adapter POE, External router
Power supply cable: Yes
Wireless LAN features
Wi-Fi frequency: 2.4 GHz / 5 GHz
Wi-Fi: Yes
Wi-Fi standards: 802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax)
MU-MIMO technology: Yes
Ports & interfaces
Number of DC inputs : 1
Number of Ethernet WAN ports: 1
Antenna
Gain: 4 dB
Antenna type: Omnidirectional / directional antenna
Mobile network
Data network: 5G, LTE
4G standard: LTE-TDD & LTE-FDD
Number of SIM cards: 1
5G bands: n1/3/7/38/40/66/75
4G bands: B1/3/4/7/8/38/39/40/41/42/48
Safety warning
Warnings: Do not expose the device to water or moisture., Do not expose the device to extreme temperatures., Do not dismantle the unit yourself, there is a risk of electric shock.
Ethernet LAN features
Ethernet LAN: Yes
Ethernet LAN interface type: Gigabit Ethernet
Warranty: warranty 24 months
