Περιγραφή
High-quality water-soluble support material that can be used with many types of polymers and easily dissolves in cold water. This eco-friendly material provides support for printed objects with overhangs or particularly complex structures. Verbatim BVOH always meets the strictest quality control standards, ensuring excellent layer formation and adhesion.
Product Details
Butenediol vinyl alcohol copolymer (BVOH) for 3D printing
Water-soluble support material
After dissolution, wastewater can be disposed of via standard sewage systems**
Excellent layer structure and adhesion quality
Best combined with ABS, PLA, and PET materials
Material is sensitive to light and UV radiation
High solubility
Main applications: Support materials for 3D printing, especially for geometrically complex parts
**To dispose of this material, at least 20 times its weight in water is required (i.e., a minimum of 20 ml of water per 1 g of BVOH) with a maximum daily disposal of 2 kg of BVOH. Higher daily usage will require professional ecological wastewater treatment.
Product Specifications
Diameter accuracy: 1.75 mm ± 0.07 mm
Net weight: 0.5 kg
Filament length: 182 m
Melting temperature: 176 "C
Melt Flow Rate @ 230 "C, 21.1N: 7.5 g/(10 minutes)
Density: 1.14 g/cm?
Vicat softening temperature: 92 "C
Glass transition temperature: 68 "C
Flexural strength: 71 MPa
Flexural modulus: 2900 MPa
Tensile Strength: 45 MPa
Elongation at break: 9.0%
Spool Dimensions
Spool diameter: 200 mm
Spool depth: 72 mm
Hub diameter: 102 mm
Hub hole diameter: 51 mm
Recommended Printer Settings
Extrusion temperature: 210±10 "C
Bed temperature: 60 "C
Print speed: 30 mm/s
