Περιγραφή
Features
(24) Gigabit RJ45 ports
(2) 10G SFP+ ports
Layer 2 and Layer 3 features
UniFi SmartPower RPS DC input
Near-silent cooling
1.3? touchscreen display
*Managed with UniFi Network Application Version: 5.12.11 or higher
Specifications
Dimensions
442.4 x 285.4 x 43.7 mm
(17.42 x 11.24 x 1.72?)
Weight
With Brackets
3.50 kg (7.72 lb)
3.59 kg (7.92 lb)
Interfaces
NetworkingManagement
(24) 10/100/1000 RJ45 Ports
(2) 1/10G SFP+ Ethernet Ports
Ethernet In-Band
Total Non-Blocking Throughput
44 Gbps
Switching Capacity
88 Gbps
Forwarding Rate
65.472 Mpps
Power Method
Universal Input
USP RPS DC Input
100-240VAC, 50/60 Hz
11.5VDC, 2.61A
Power Supply
AC/DC, Internal, 36W
Voltage Range
100 to 240VAC
Max Power Consumption
30W
LEDs
RJ45 Data Ports
SFP+ Data Ports
Speed/Link/Activity
Link/Activity
ESD/EMP Protection
Air: ± 16 kV, Contact: ± 12 kV
Shock and Vibration
ETSI300-019-1.4 Standard
Operating Temperature
-5 to 45° C (23 to 113° F)
Operating Humidity
10 - 90% Noncondensing
Certifications
CE, FCC, IC
