Περιγραφή
Χαρακτηριστικά o Includes full UniFi application suite for device management
o 3.5+ Gbps routing
o Integrated 8-port PoE/PoE+ switch
o (1) 10G SFP+, (8) GbE RJ45 LAN ports including (2) PoE+, and (6) PoE
o (1) 10G SFP+, (1) 2.5 GbE RJ45 WAN ports
o 1.3? touchscreen
o 128 GB SSD & 3.5? HDD bay Specifications
Mechanical
Dimensions
442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2?)
Weight
4.95 kg (10.9 lb)
Enclosure materials
Aluminium CNC, SGCC steel
Mount material
SGCC steel
Hardware
Processor
Quad-core ARM(R) Cortex(R)-A57 at 1.7 GHz
System memory
4 GB DDR4
On-board storage
16 GB eMMC
Integrated 128 GB SSD
Management interface
Ethernet
Bluetooth
Networking interface
(8) LAN: GbE RJ45 ports
(1) WAN: 2.5 GbE RJ45 port
SFP+ interface
(1) LAN: 10G SFP+
(1) WAN: 10G SFP+
PoE interface
(6) PoE (Pair A 1, 2+; 3, 6-)
(2) PoE+ (Pair A 1, 2+; 3, 6-)
IDS/IPS throughput
3.5 Gbps*
*Measured with iPerf3
Power method
(1) Universal AC input, 100--240V AC, 4.4A Max., 50/60 Hz
(1) USP-RPS DC input, 52V DC, 3.94A
Power supply
AC/DC, internal, 240W
Supported voltage range
100--240V AC
Max. power consumption
50W (Excluding PoE output)
Max. PoE wattage per port by PSE
PoE: 15.4W
PoE+: 30W
Voltage range PoE mode
PoE: 44--57V
PoE+: 50--57V
ESD/EMP protection
Air: ± 15kV, contact: ± 8kV
LCM display
(1) 1.3? touchscreen
Button
Factory reset
Operating temperature
-10 to 40° C (14 to 104° F)
Operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
LEDs
Ethernet
White: link/activity
SFP+
White: link/activity
HDD
White: disk activity
Amber: disk error
RPS
Blue: ready
