Ubiquiti - (UAP-NanoHD)

Description
UniFi nanoHD

Compact 802.11ac Wave2 MU-MIMO Enterprise Access Point.
4x4 MU-MIMO on 5GHz (1733Mbps max PHY rate), 2x2 MIMO on 2.4GHz (300Mbps max PHY rate)

802.3af

Same mount as UAP-AC-Lite.
Specifications


Dimensions
160 x 160 x 32.65 mm (6.3 x 6.3 x 1.29?)


Weight

With Mounting Kits
300 g (10.6 oz)

315 g (11.1 oz)


Networking Interface
(1) RJ45 GbE


Buttons
(1) Reset to Defaults


Power Method
802.3af


Power Supply
UniFi Switch (PoE)


Max. Power Consumption
10.5W


Operating Frequency
2.4 GHz

5 GHz


Max. TX Power

2.4 GHz

5 GHz
23 dBm

26 dBm


Antenna Gain

2.4 GHz

5 GHz
2.8 dBi

3 dBi


MIMO

2.4 GHz

5 GHz
2x2

4x4


Throughput

2.4GHz

5GHz
300 Mbps

1733 Mbps


Wi-Fi Standards
802.11 a/b/g/n/ac/ac-wave2


Wireless Security
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)


BSSID
8 per Radio


Mounting
Wall/Ceiling (Kits Included)


Operating Temperature
-10 to 70° C (14 to 158° F)


Operating Humidity
5 to 95% Noncondensing


Certifications
CE, FCC, IC


*Optional skins sold separately
