Περιγραφή
Features:
WiFi 6 support (2.4/5 GHz bands)
5.3 Gbps aggregate throughput rate
(1) GbE RJ45 port (PoE In)
(4) GbE RJ45 ports, including one that supports PoE output*
Specifications
Mechanical
Dimensions
139.66 x 96 x 31.19 mm (5.5 x 3.78 x 1.28?)
Weight
460 g (1.01 lb)
Enclosure materials
Plastic, aluminum
Mount material
Aluminum
Hardware Management interfaces Ethernet
Bluetooth
Networking interfaces (1) Data-in: 1GbE RJ45 port
(4) Data-out: 1GbE RJ45 ports
PoE interfaces (1) PoE in (PoE output not used)
(1) PoE out (requires a PoE+ switch)
Button
Factory reset
LED
White/blue
Power method
PoE
Power supply UniFi PoE switch
48V, 0.5A PoE adapter (optional)
Max. power consumption
Excluding PoE output: 13.5W
Max PoE wattage per port by PSE 15.4W*
*Requires a PoE+ switch
Voltage range PoE mode
44--57V DC
Max. TX power 2.4 GHz
5 GHz
MIMO 2.4 GHz
5 GHz
Throughput rate 2.4 GHz
5 GHz
Antenna gain 2.4 GHz
5 GHz
Operating temperature
-30 to 60° C (-22 to 140° F)
Operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Software
WiFi standards 802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID
8 per radio
VLAN
802.1Q
Advanced QoS
Per-user rate limiting
Guest traffic isolation
Supported
Concurrent clients
300+
Zero-wait DFS
Yes
Supported Data Rates
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b
1, 2, 5.5, 11 Mbps
802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)
6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5)
6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6)
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
