Description
Electrostatic discharge (ESD) is the leading cause for outdoor device failures. You can effectively protect against ESD damage using a grounded Ubiquiti PoE Adapter, TOUGHCableTM, and TOUGHCable Connectors.
Ubiquiti PoE Adapters provide a variety of features to help protect your PoE devices:
Surge protection
Clamping protection
Maximum surge discharge
Peak pulse current
AC cable with earth ground
Specifications
Dimensions
87 x 44 x 29 mm
(3.43 x 1.73 x 1.14?)
Weight
92 g
(3.25 g)
Output Voltage
24VDC @ 0.5A
LAN Activity Indicator
No
Gigabit LAN Port
No
Remote Reset Capability
Yes
Reset Button
Yes
Rated Voltage
100-240VAC @ 50/60Hz
Input Current
0.3A @ 120VAC, 0.2A @ 240VAC
Inrush Current
Efficiency
75+%
Output Ripple
1% Max.
Switching Frequency
50 kHz
Line Regulation
<= 3%
Load Regulation
<= 5%
2-Pair Powering
Pins 4, 5 (+) and Pins 7, 8 (-)
4-Pair Powering
-
Operating Temperature
0 to 40° C
(32 to 104° F)
Storage Temperature
-30 to 70°C
(-22 to 158° F)
Operating Humidity
35 to 95% Noncondensing
AC Connector
IEC-320 C6
Data IN / POE
RJ45 Shielded Socket
Surge Protection
Difference and Common Mode
Clamping Protection
11V Data, 60V Power
Max. Surge Discharge
1500A (8/20 μs) Power
Peak Pulse Current
36A (10/1000 μs) Data
Shunt Capacitance
Response Time
Certifications
CE, FCC, IC, UL
