Description
The Ubiquiti NanoSwitch is an unmanaged switch with four Gigabit Ethernet ports.
For its total non-blocking line rate, the NanoSwitch 4 Port supports up to 4 Gbps.
Featuring a durable, weatherproof form factor, the NanoSwitch is ideal for outdoor deployment and for use with the Ubiquiti airMax and UniFi Video range.
Specifications
Dimensions
196.4*93.5*32.4mm
7.73*3.68*1.28inch
Weight
269g
9.5oz
Enclosure Characteristics
White Polycarbonate
Processor
RTL8367N-VB
On-Board Flash Storage
4Kbits
Total Non-Blocking Line Rate
4Gbps
TYP. Power Consumption
1.5W
Power Method
Passive 24V PoE-in
Supported Voltage Range
Passive 24V PoE-in
Networking Interfaces
(4) 10/100/1000 Mbps Ethernet RJ45
PoE Interfaces
Passive 24V PoE-in
Max PoE+ Wattage per Port by PSE
24V@1A per port / Total
[email protected] for three ports
Passive PoE Max wattage per port
24W per port / Total 36W for three ports
Operating Temperature
-30C ~ 70C
Operating Humidity
5 to 95% Non-Condensing
