Περιγραφή
Design
LED indicators: Yes
Rack mounting: No
Product colour: Black
Stackable: No
Wall mountable: Yes
Power
Power supply included: Yes
Input current: 0.6 A
DC input voltage: 5 V
Power consumption (max): 2.7 W
Surge protection: Yes
Surge protection voltage: 6 kV
Power source: DC
Security
Loop protection: Yes
IGMP snooping: Yes
DHCP features: DHCP client
Queue scheduling algorithms: Weighted Round Robin (WRR)
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -5 - 45 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 9.09 BTU/h
Management features
Web-based management: Yes
Switch layer: L2
Quality of Service (QoS) support: Yes
Cloud-managed: Yes
Switch type: Managed
Unified static configuration: Yes
Weight & dimensions
Depth: 100.7 mm
Width: 158 mm
Height: 25.4 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ab, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3i
Virtual LAN features: Port-based VLAN, Tagged VLAN, MTU VLAN
Auto-negotiation: Yes
Link aggregation: Yes
Number of VLANs: 32
Port mirroring: Yes
Auto MDI/MDI-X: Yes
10G support: No
VLAN support: Yes
Flow control support: Yes
Fast leave: Yes
Zero Touch Provisioning (ZTP): Yes
Performance
Firmware upgradeable: Yes
Mean time between failures (MTBF): 1141726 h
Fanless: Yes
Flash memory: 64 MB
Packaging data
AC adapter included: Yes
Package type: Box
Packaging content
User guide: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Data transmission
Jumbo frames: 15000
Forwarding rate: 11.9 Mpps
MAC address table: 8000 entries
Store-and-forward: Yes
Jumbo frames support: Yes
Switching capacity: 16 Gbit/s
Packet buffer memory: 4 MB
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Warranty: warranty 60 months
