Περιγραφή
Design
Reset button: Yes
Wall mountable: Yes
Product colour: Black
LED indicators: Yes
Power
DC input voltage: 53.5 V
Power supply included: Yes
Input current: 1.31 A
Surge protection: Yes
Power source: DC
Surge protection voltage: 6 kV
Security
DHCP features: DHCP client
IGMP snooping: Yes
Loop protection: Yes
Queue scheduling algorithms: Weighted Round Robin (WRR)
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): -5 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Cloud-managed: Yes
Web-based management: Yes
Switch type: Managed
Quality of Service (QoS) support: Yes
Unified static configuration: Yes
Weight & dimensions
Width: 158 mm
Height: 25 mm
Depth: 101 mm
Network
Networking standards: IEEE 802.3at, IEEE 802.1p, IEEE 802.1ab, IEEE 802.1Q, IEEE 802.3x
Auto MDI/MDI-X: Yes
Flow control support: Yes
Port mirroring: Yes
Virtual LAN features: Port-based VLAN, MTU VLAN, Tagged VLAN
Link aggregation: Yes
VLAN support: Yes
10G support: No
Auto-negotiation: Yes
Fast leave: Yes
Zero Touch Provisioning (ZTP): Yes
Performance
Fanless: Yes
Firmware upgradeable: Yes
Packaging data
Package type: Box
AC adapter included: Yes
Packaging content
User guide: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 6
Basic switching RJ-45 Ethernet ports quantity: 6
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
Packet buffer memory: 4 MB
Jumbo frames: 15
Forwarding rate: 7.4 Mpps
Store-and-forward: Yes
Switching capacity: 12 Gbit/s
MAC address table: 8000 entries
Jumbo frames support: Yes
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 65 W
Power over Ethernet plus (PoE+) ports quantity: 4
Power over Ethernet (PoE) type supported: PoE+
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) power per port: 30 W
Optical fiber
Transmission distance (max): 0.25 km
Warranty: warranty 36 months
