Περιγραφή
Design
LED indicators: Yes
Product colour: Black
Form factor: 1U
Rack mounting: Yes
Number of fans: 2 fan(s)
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power supply included: Yes
Power source: AC
Power consumption (typical): 15 W
Security
Security algorithms: SSL/TLS, SSH, HTTPS, SSH-2
MAC address filtering: Yes
Authentication type: AAA, TACACS+
IP-MAC-Port binding: Yes
Queue scheduling algorithms: Weighted Round Robin (WRR), WRR+SP, SP
BPDU filtering/protection: Yes
Access Control List (ACL): Yes
IGMP snooping: Yes
DHCP features: DHCP snooping, DHCP server, DHCPv6 client, DHCPv6 snooping, DHCP client, DHCP relay
Password protection: Yes
Authentication: MAC-based authentication, Port-based authentication
Static port security: Yes
Loop protection: Yes
SSH/SSL support: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 0 - 50 °C
Storage relative humidity (H-H): 5 - 90%
Heat dissipation: 51.18 BTU/h
Operating relative humidity (H-H): 10 - 90%
Management features
Web-based management: Yes
Cloud-managed: Yes
Traffic classification: Yes
ARP inspection: Yes
Configuring Location Settings (CLI): Yes
MIB support: RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213
Switch type: Managed
Quality of Service (QoS) support: Yes
Switch layer: L2+
System event log: Yes
Weight & dimensions
Width: 294 mm
Height: 44 mm
Depth: 180 mm
Network
Ethernet LAN data rates: 100,1000,2500 Mbit/s
Networking standards: IEEE 802.1D, IEEE 802.1s, IEEE 802.1w
Virtual LAN features: MAC address-based VLAN, Protocol-based VLAN, Voice VLAN, Port-based VLAN, Private VLAN, Tagged VLAN
Spanning tree protocol: Yes
IP routing: Yes
Head-of-line (HOL) blocking: Yes
10G support: Yes
Port mirroring: Yes
Flow control support: Yes
VLAN support: Yes
Number of VLANs: 4000
Rate limiting: Yes
Broadcast storm control: Yes
Link aggregation: Yes
Performance
Fanless: Yes
Packaging data
Package weight: 2.84 kg
Package type: Box
Package height: 80 mm
Package depth: 250 mm
Package width: 528 mm
Packaging content
Quick start guide: Yes
Cables included: AC
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Management protocols: SNMPv1/v2c/v3, SNTP
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
SFP+ module slots quantity: 2
2.5G Ethernet (copper) ports quantity: 8
Power connector: AC-in jack
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Console port: RJ-45/Micro-USB
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Number of IP interfaces: 16
Jumbo frames: 9000
Static route: Yes
Forwarding rate: 59.52 Mpps
Number of static routes: 48
Switching capacity: 80 Gbit/s
MAC address table: 16000 entries
Packet buffer memory: 12 MB
Jumbo frames support: Yes
Multicast features
Multicast Listener Discovery (MLD) snooping: Y
Multicast support: Yes
Warranty: warranty 60 months
