Περιγραφή
Design
Product colour: Black
Wall mountable: Yes
LED indicators: Yes
Reset button: Yes
Power
DC input voltage: 53.5 V
Power source: AC/DC
Power supply included: Yes
Security
Loop protection: Yes
DHCP features: DHCP client
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Management features
Cloud-managed: Yes
Quality of Service (QoS) support: Yes
Switch type: Managed
Weight & dimensions
Depth: 98 mm
Width: 100 mm
Height: 25 mm
Network
Virtual LAN features: Tagged VLAN, Port-based VLAN, MTU VLAN
Auto-negotiation: Yes
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.1p, IEEE 802.3at, IEEE 802.1ab
VLAN support: Yes
Link aggregation: Yes
Auto MDI/MDI-X: Yes
10G support: No
Flow control support: Yes
Port mirroring: Yes
Performance
Fanless: Yes
Packaging data
Package type: Box
Packaging content
User guide: Yes
Certificates
Compliance certificates: RoHS, CE, Federal Communications Commission (FCC)
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
MAC address table: 8000 entries
Switching capacity: 10 Gbit/s
Forwarding rate: 7.4 Mpps
Packet buffer memory: 4 MB
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 15
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 4
Power over Ethernet plus (PoE+) ports quantity: 4
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 65 W
Power over Ethernet (PoE) power per port: 30 W
Safety warning
Warnings: Do not open the case or try to repair it yourself., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Ensure the unit is adequately ventilated during operation.
Optical fiber
Transmission distance (max): 0.25 km
Warranty: warranty 60 months
