Περιγραφή
Design
Number of fans: 0 fan(s)
LED indicators: Yes
Wall mountable: Yes
Product colour: Black
Power
AC input frequency: 50 Hz
Power source: DC/PoE
Input current: 0.81 A
AC input voltage: 220 V
Power supply included: Yes
DC input voltage: 53.5 V
Power consumption (max): 46.45 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Heat dissipation: 157.93 BTU/h
Management features
Quality of Service (QoS) support: Yes
Switch type: Unmanaged
Weight & dimensions
Depth: 98 mm
Width: 100 mm
Height: 25 mm
Network
Cable types supported: Cat4, Cat3, Cat5, Cat5e
Networking standards: IEEE 802.3i, IEEE 802.3x, IEEE 802.3af, IEEE 802.3u
Auto-negotiation: Yes
10G support: No
Flow control support: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX
Auto MDI/MDI-X: Yes
Performance
Fanless: Yes
Packaging data
Package type: Box
Packaging content
User guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Data transmission
Store-and-forward: Yes
Forwarding rate: 0.744 Mpps
Jumbo frames support: Yes
MAC address table: 2000 entries
Switching capacity: 1 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE) ports quantity: 4
Power over Ethernet (PoE) power per port: 15.4 W
Power over Ethernet (PoE): Yes
Safety warning
Warnings: The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Do not open the case or try to repair it yourself.
Warranty: warranty 60 months
