Περιγραφή
Design
Product colour: Black
LED indicators: Yes
Power
AC input voltage: 220 V
Power supply included: Yes
AC input frequency: 50 Hz
Power consumption (max): 74.46 W
Power source: DC/PoE
DC input voltage: 53.5 V
Security
IGMP snooping: Yes
Operational conditions
Heat dissipation: 253.16 BTU/h
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Management features
Switch type: Unmanaged
Quality of Service (QoS) support: Yes
Weight & dimensions
Width: 99.8 mm
Height: 25 mm
Depth: 98 mm
Network
Networking standards: IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3i, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Cable types supported: Cat4, Cat3, Cat5, Cat5e
Auto MDI/MDI-X: Yes
10G support: No
MAC address auto-learning supported: Yes
Auto-negotiation: Yes
Flow control support: Yes
MAC address auto-aging supported: Yes
Packaging data
User guide: Yes
Package type: Box
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
Store-and-forward: Yes
Forwarding rate: 7.44 Mpps
MAC address table: 2000 entries
Switching capacity: 10 Gbit/s
Jumbo frames: 16000
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 65 W
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 4
Power over Ethernet (PoE) power per port: 30 W
Warranty: warranty 60 months
