Technical details
Compliance certificates: BSMI, RoHS, CE, Federal Communications Commission (FCC)
Design
Component for: PC
Internal: Yes
LED indicators: Status
Product colour: Green, Grey
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Depth: 120.8 mm
Width: 78.5 mm
Height: 21.5 mm
Network
Quality of Service (QoS) support: Yes
Full duplex: Yes
Cabling technology: 10/100/1000BaseT(X)
Ethernet LAN: Yes
Maximum operating distance: 100 m
Ethernet interface type: Gigabit Ethernet
Auto-negotiation: Yes
VLAN tagging: Yes
Auto MDIX IEEE: Yes
Wake-on-LAN ready: Yes
Networking standards: IEEE 802.1Q, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u
Ethernet LAN data rates: 100 Mbit/s, 1000 Mbit/s, 10
Maximum data transfer rate: 2000 Mbit/s
System requirements
Windows operating systems supported: Windows 8 x64, Windows 10 Education, Windows 10 Home, Windows 7 Starter x64, Windows 8.1, Windows 7 Ultimate x64, Windows 7 x64, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 10 Enterprise, Windows 10 Home x64, Windows 8, Windows 10 Pro x64, Windows 8 Enterprise, Windows 7 Home Basic x64, Windows 8.1 Enterprise, Windows 7 Professional, Windows 7, Windows 10 Education x64, Windows 10, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows 8 Pro x64, Windows 8.1 Pro, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 IoT Enterprise, Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Ultimate, Windows 7 Professional x64, Windows 10 Enterprise x64, Windows 10 x64
Packaging data
Package width: 160 mm
Package depth: 135 mm
Package height: 30 mm
Package weight: 100 g
Packaging content
Quick installation guide: Yes
Mounting brackets included: Yes
Resource CD: Yes
Ports & interfaces
Interface: Ethernet
Host interface: PCI Express
Ethernet LAN (RJ-45) ports: 1
Connectivity technology: Wired
Other features
Flow control support: Yes
Logistics data
Harmonized System (HS) code: 85176990
Sustainability
Sustainability compliance: Yes
Warranty: warranty 36 months
