Description
Superior WiFi 6 Speeds: Delivers dual-band speeds of up to 1.8 Gbps powered by the latest WiFi 6 technology
Higher Network Efficiency: Enjoy faster speeds on more devices with less lag via OFDMA and MU-MIMO
Long-Range Coverage: Dedicated high-power amplifier and professional antennas with IP67 weatherproof enclosure
Omada Mesh Technology: Enables wireless connectivity between access points for extended range and flexible deployment**
Stay Smooth with Fast Roaming: Users can enjoy seamless streaming across the property with their devices switching effortlessly between access points**
Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management
Features
o AX1800 Indoor/Outdoor Dual-Band Wi-Fi 6 Access Point
o 1x Gigabit RJ45 Port
o 574Mbps @ 2.4 GHz + 1201 Mbps @ 5 GHz
o 802.3at PoE and Passive PoE
o IP67 Weatherproof
o 4xInternal Antennas
o Mesh
o Seamless Roaming
o MU-MIMO
o Band Steering
o Beamforming
o Load Balance
o Airtime Fairness
o Centralized Management by Omada SDN Controller
o Omada App
Specifications
Hardware Features
Interface
1x Gigabit Ethernet (RJ-45) Port (Support 802.3at PoE and Passive PoE)
Button
Reset
Power Supply
o 802.3at PoE
o 48V/0.5A Passive PoE (PoE Adapter Included)
Power Consumption
o EU: 12.5W (802.3at PoE or Passive PoE)
o US: 14.7W (802.3at PoE or Passive PoE)
Dimensions ( W x D x H )
o 280.4x106.5x56.8 mm (without antenna & mounting kit)
Antenna
o 2.4 GHz: 2x 4 dBi
o 5 GHz: 2x 5 dBi
Weatherproof Enclosure
IP67
Mounting
Pole/Wall Mounting (Kits included)
Wireless Features
Wireless Standards
IEEE 802.11ax/ac/n/g/b/a
Frequency
2.4 GHz, 5 GHz
Signal Rate
o 802.11ax: 8 Mbps to 1201 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80)
o 802.11ac: 6.5 Mbps to 867 Mbps (MCS0-MCS9, NSS = 1 to 2 VHT20/40/80)
o 802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40)
o 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
o 802.11b: 1, 2, 5.5, 11 Mbps
o 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Transmit Power
o CE:
o FCC:
Wireless Functions
o 1024-QAM
o 4x Longer OFDM Symbol
o OFDMA
o Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
o Enable/Disable Wireless Radio
o Automatic Channel Assignment
o Transmit Power Control (Adjust Transmit Power on dBm)
o QoS (WMM)
o MU-MIMO
o Omada Mesh**
o Seamless Roaming**
o Band Steering
o Load Balance
o Airtime Fairness
o Beamforming
o Rate Limit
o Reboot Schedule
o Wireless Schedule
o Wireless Statistics based on SSID/AP/Client
Wireless Security
o Captive Portal Authentication**
o Access Control
o Wireless Mac Address Filtering
o Wireless Isolation Between Clients
o SSID to VLAN Mapping
o Rogue AP Detection
o 802.1X Support
o WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Management
Omada App
Yes
Centralized Management
o Omada Hardware Controller (OC300)
o Omada Hardware Controller (OC200)
o Omada Software Controller
Cloud Access
Yes, through
o OC300
o OC200
o Omada Software Controller
Email Alerts
Yes
Management MAC Access Control
Yes
SNMP
v1, v2c
System Logging Local/Remote Syslog
Yes
SSH
Yes
Web-based Management
Yes
L3 Management
Yes
Multi-site Management
Yes
Management VLAN
Yes
Others
Certification
CE, FCC, RoHS
Package Contents
o Access Point EAP610-Outdoor
o Passive PoE Adapter
o Power Cord
o Mounting Kits
o Installation Guide
System Requirements
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Environment
o Operating Temperature: -30-70 °C (-22-158 °F)
o Storage Temperature: -40-70 °C (-40-158 °F)
o Operating Humidity: 10-90% RH non-condensing
o Storage Humidity: 5-90% RH non-condensing
