Περιγραφή
Design
Product colour: Black
Rack mounting: No
Stackable: No
LED indicators: Yes
Power
Power source: DC/PoE
DC input voltage: 48 V
AC input voltage: 100 - 220 V
Power consumption (max): 64.44 W
Power supply included: Yes
AC input frequency: 50 Hz
Input current: 1.25 A
Security
IGMP snooping: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Heat dissipation: 219.87 BTU/h
Management features
Quality of Service (QoS) support: Yes
Switch type: Unmanaged
Weight & dimensions
Width: 99.8 mm
Height: 25 mm
Depth: 98 mm
Network
Cable types supported: Cat3, Cat4, Cat6, Cat5, Cat5e
Flow control support: Yes
10G support: No
Networking standards: IEEE 802.3x, IEEE 802.3u, IEEE 802.3, IEEE 802.1p, IEEE 802.3af
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-T, 10BASE-T
MAC address auto-aging supported: Yes
VLAN support: Yes
MAC address auto-learning supported: Yes
Auto MDI/MDI-X: Yes
Auto-negotiation: Yes
Performance
Fanless: Yes
Maximum cable length: 100 m
Packaging data
AC adapter included: Yes
Package depth: 196 mm
Package width: 131 mm
Package type: Box
Package height: 121 mm
Package weight: 761 g
Packaging content
User guide: Yes
Quick start guide: Yes
Cables included: AC
Manual: Yes
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 5
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Store-and-forward: Yes
MAC address table: 2000 entries
Forwarding rate: 7.44 Mpps
Switching capacity: 10 Gbit/s
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 56 W
Power over Ethernet (PoE) ports quantity: 4
Power over Ethernet (PoE): Yes
Sustainability
Sustainability compliance: Yes
Warranty: warranty 60 months
