Περιγραφή
Design
LED indicators: Yes
Product colour: Black
Housing material: Steel
Wall mountable: Yes
Rack mounting: No
Power
Power consumption (max): 2.3 W
Input current: 0.6 A
AC input voltage: 220 V
AC input frequency: 50 Hz
Power supply included: Yes
Security
IGMP snooping: Yes
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70 °C
Heat dissipation: 7.83 BTU/h
Management features
Quality of Service (QoS) support: Yes
Switch type: Unmanaged
Switch layer: L2
Weight & dimensions
Depth: 98 mm
Width: 100 mm
Height: 25 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.1p
Auto-negotiation: Yes
MAC address auto-aging supported: Yes
Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T
MAC address auto-learning supported: Yes
Cable types supported: Cat5, Cat5e, Cat3, Cat4
Flow control support: Yes
10G support: No
Auto MDI/MDI-X: Yes
Full duplex: Yes
Packaging data
Package type: Box
Packaging content
Cables included: AC
User guide: Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports quantity: 5
Gigabit Ethernet (copper) ports quantity: 5
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 10 Gbit/s
MAC address table: 2048 entries
Packet buffer memory: 1 MB
Forwarding rate: 7.4 Mpps
Store-and-forward: Yes
Jumbo frames support: Yes
Jumbo frames: 16000
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Warranty: warranty 60 months
