Περιγραφή
Design
Base plate material: Copper
Radiator material: Aluminum
Fan connector: 4-pin
Illumination colour: Multi
Product colour: Black
Illumination LED: Yes
Number of heat pipes: 3
Number of fans: 1 fan(s)
Fins material: Aluminium
Power
Fan voltage: 12 V
LED voltage: 5 V
Fan current: 0.2 A
Fan power consumption: 2.4 W
Thermal Design Power (TDP): 150 W
Weight & dimensions
Package width: 145 mm
Width: 93 mm
Depth: 64 mm
Height: 132 mm
Weight: 248 g
Package height: 117 mm
Package depth: 105 mm
Fan dimensions (W x D x H): 90 x 25 x 90 mm
Performance
Fan speed (min): 800 RPM
Suitable location: Processor
Fan noise level (min): 9 dB
Supported processor sockets: LGA 1851, Socket AM4, LGA 1150 (Socket H3), Socket AM5, LGA 1151 (Socket H4), Intel LGA1851, LGA 1156 (Socket H), LGA 1700, LGA 1200 (Socket H5), LGA 775 (Socket T), LGA 1366 (Socket B), LGA 1155 (Socket H2)
Fan diameter: 9 cm
Fan noise level (max): 28 dB
Pulse-width modulation (PWM) support: Yes
Fan speed (max): 2600 RPM
Fan's mean time to failure (MTTF): 60000 h
Bearing type: Hydraulic
Maximum airflow: 67 cfm
Minimum air pressure: 0.8 mmH2O
Quantity per pack: 1 pc(s)
Maximum air pressure: 1.25 mmH2O
Type: Air cooler
Packaging content
Package type: Box
Manual: Yes
Other features
Anti-vibration system: Yes
Thermal grease: Yes
Warranty: warranty 24 months
