Περιγραφή
Features
Complies with ATX 12V version 2.3V
80+ BRONZE
Active PFC Circuit
Mate Black Casing
With 120x120x25mm Silent Fan
Dimensions: 140x148x85mm
Specifications
Input Range: 185Vac / 230Vac
Frequency: 50-60Hz
Input Current: 650W: 4A FOR 240Vac
Efficiency: 80% at full load, nominal line
Inrush Current: The maximum inrush current shall be less than 60A peak from a coId start at any Iine voItage
Output
Max 650W
Hold up time: >12ms at full load nominal line
Rise time: <20ms at full load nominal line
Over Voltage protection: +3.3V +5V +12V
Over Power protection: Latch off
Power good Signal: TTL Compatible
DC Connectors: ATX 20+4pin *1 EPS 4+4pin *2 PCI-E 6+2pin *2 SATA *2 Peripheral 4pin *2 Floppy *1 Environmental Operating temperature: 5C to 40C Storage temperature: -20C to 70C MTBF: >50000hrs at 80% load 25C ambient EMI/RFI FCC Part 15 Class B, CISPR 22 Class B, CE SAFETY CUL, TUV, CB, CSA, RoHS CompliantΚατασκευαστής : Supercase
Τύπος : Active PFC
Μέγιστη Ισχύς : 650 Watt
Αποσπώμενα καλώδια : Όχι
PCI Express : 2x
SATA : 6x
Molex : 2x
Protections : CUL, TUV, CB, CSA, RoHS Compliant
Λοιπά Χαρακτηριστικά : ATX 20+4pin *1 EPS 4+4pin *2 PCI-E 6+2pin *2 SATA *6 Peripheral 4pin *2 Floppy *1
Energy-Efficiency : 80+ Bronze
Part Number : FP-650W
Μεικτό βάρος : 5 kg
Καθαρό βάρος : 3 kg
EAN Number : 0644216964291
Εγγύηση : 2 έτη
