SPARKLE Intel Arc B580 Titan Nox Oc 12G Graphics Card - (SB580TB-12GOC)

Processor
Maximum displays per videocard: 4
Ray accelerators: 20
Graphics processor: Arc A770 TITAN OC Edition
Graphics processor family: Intel
Maximum resolution: 7680 x 4320 pixels
Processor frequency: 2740 MHz
CUDA: No

Memory
Graphics card memory type: GDDR6
Discrete graphics card memory: 12 GB
Memory bandwidth (max): 456 GB/s
Memory bus: 192 bit

Design
Cooling type: Active
Number of slots: 2.2
Number of fans: 3 fan(s)
Product colour: Black

Power
Supplementary power connectors: 1x 8-pin
Power consumption (typical): 200 W
Minimum system power supply: 600 W

Weight & dimensions
Depth: 44 mm
Height: 117 mm
Length: 315 mm
Weight: 954 g

System requirements
Windows operating systems supported: Windows 10, Windows 11
Minimum RAM: 8000 MB

Performance
Intel(R) Xe Matrix Extensions (Intel(R) XMX) Engines: 160
Xe-cores: 20
OpenCL version: 3.0
DirectX version: 12 Ultimate
TV tuner integrated: No
Dual Link DVI: No
OpenGL version: 4.6

Packaging data
Package type: Box

Ports & interfaces
HDMI ports quantity: 1
Interface type: PCI Express x8 4.0
HDMI version: 2.1
DisplayPorts quantity: 3
DisplayPort version: 2.1

Other features
HDMI: Yes


Warranty: warranty 36 months
