Sapphire PURE B850A WIFI 7 AMD B850 Socket AM5 ATX - (52123-11-40G)

Processor
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, AMD Ryzen 7000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Supported processor sockets: Socket AM5

Graphics
Parallel processing technology support: Not supported

Features
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64, Windows 11
Motherboard form factor: ATX
Product colour: White
Motherboard chipset family: AMD
Audio chip: Realtek ALC897
Motherboard chipset: AMD B850

Memory
Maximum internal memory per slot: 64 GB
Memory channels: Dual-channel
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Maximum internal memory: 256 GB
Number of memory slots: 4
Supported memory clock speed (max): 8000 MHz

Weight & dimensions
Depth: 244 mm
Width: 305 mm

Network
Wi-Fi: Yes
LAN controller: Dragon RTL8125BG
Wi-Fi standards: Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11g, Wi-Fi 6E (802.11ax), 802.11b
Ethernet LAN: Yes
Bluetooth: Yes
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)

Internal I/O
Front panel connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
Number of CPU fan connectors: 1
Number of RGB LED pin headers: 3
Serial port headers: 1
ATX Power connector (24-pin): Yes
Number of water pump connectors: 1
CPU fan connector: Yes
Audio connector: Yes
USB 2.0 connectors: 1
Number of chassis fan connectors: 3
12V power connector: Yes
RGB LED pin header: Yes

Packaging content
Antenna included: Yes

Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Number of storage drives supported: 7

Rear panel I/O ports
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 6
Line-in: Yes
Microphone in: Yes
USB connector type: USB Type-A, USB Type-C
WiFi-AP antenna jack: 2
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
HDMI ports quantity: 1

Expansion slots
1st M.2 largest key size: 2280
Number of M.2 (M) slots: 3
1st M.2 highest PCI Express generation: 5.0
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
PCI Express x4 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
3rd M.2 highest PCI Express generation: 4.0
3rd M.2 largest key size: 2280


Warranty: warranty 36 months
