Technical details
Compliance certificates: UKCA, UL, REACH, RoHS, CE
Warranty period: 6 year(s)
Design
Material: Rubber, Polybutylene terephthalate (PBT), Silicone
Fan connector: 4-pin
Product colour: Bronze
Number of fans: 1 fan(s)
Number of fan blades: 7
Power
Fan current: 0.17 A
Rated voltage: 5 V
Power protection features: Over voltage, Over current
Starting voltage: 4 V
Fan power consumption: 0.85 W
Weight & dimensions
Package depth: 110 mm
Package weight: 110 g
Fan weight: 40 g
Package height: 18 mm
Package width: 140 mm
Fan dimensions (W x D x H): 60 x 15 x 60 mm
Performance
Maximum airflow: 13.77 cfm
Maximum air pressure: 2.43 mmH2O
Fan speed (min): 0 RPM
Fan speed (max): 3500 RPM
Suitable location: Computer case
Airflow: 23.4 m³/h
Fan noise level (max): 19.8 dB
Quantity per pack: 1 pc(s)
Pulse-width modulation (PWM) support: Yes
Type: Fan
Operating temperature (T-T): -10 - 70 °C
Bearing type: Self-Stabilising Oil-pressure Bearing (SSO)
Fan diameter: 6 cm
Fan's mean time to failure (MTTF): 150000 h
Packaging content
Cables included: 4-pin
Mounting kit: Yes
Screws included: Yes
Warranty: Manufacturer warranty 72 months
