Design
LED indicators: Activity, Power, Link
Rack mounting: No
Housing material: Metal
Wall mountable: Yes
Product colour: Black
Power
Power consumption (max): 3.04 W
Operational conditions
Operating altitude: 0 - 3000 m
Operating relative humidity (H-H): 0 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 0 - 95%
Heat dissipation: 10.4 BTU/h
Storage temperature (T-T): -20 - 70 °C
Management features
Switch layer: L2
Quality of Service (QoS) support: Yes
Switch type: Unmanaged
Weight & dimensions
Weight: 390 g
Height: 29 mm
Depth: 101 mm
Width: 158 mm
Network
Networking standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3az, IEEE 802.3i
Auto MDI/MDI-X: Yes
Auto-sensing: Yes
Copper ethernet cabling technology: 10BASE-T, 1000BASE-T, 100BASE-TX
Flow control support: Yes
10G support: No
Cable length detection: Yes
Performance
Mean time between failures (MTBF): 3711898 h
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 8
Power connector: DC-in jack
Gigabit Ethernet (copper) ports quantity: 8
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 8000 entries
Packet buffer memory: 128 MB
Forwarding rate: 1.448 Mpps
Jumbo frames support: Yes
Latency (1 Gbps): 2.6 μs
Switching capacity: 16 Gbit/s
Jumbo frames: 9216
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Warranty: Manufacturer warranty 36 months
