Περιγραφή
Design
Product colour: Blue
Stackable: No
Safety: UL (UL 1950), CUL, C-Tick
Rack mounting: No
Power
Power source: DC
Power supply included: Yes
Power consumption (typical): 3.7 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Management features
Switch type: Unmanaged
Weight & dimensions
Weight: 500 g
Height: 29 mm
Depth: 101 mm
Width: 158 mm
Network
Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u
Copper ethernet cabling technology: 1000BASE-T, 10BASE-T, 100BASE-TX
Full duplex: Yes
Flow control support: Yes
10G support: No
Packaging data
Included power plug types: EU
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Other features
Networking features: Gigabit Ethernet
Power requirements: 12V / 1.5A
Connectivity LEDs: Y
Latency: 40 μ
Electromagnetic emissions: CE, FCC Part 15 Class A, EN 55 022 (CISPR 22), Class A VCCI
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 8000 entries
Supported data transfer rates: 10/100/1000 Mbps
Maximum data transfer rate: 1 Gbit/s
Switching capacity: 16 Gbit/s
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Safety warning
Warnings: Electronic devices should be recycled in accordance with local regulations., Do not open the housing of the unit due to the risk of electric shock., Do not use the device in damp conditions to avoid a short circuit.
Warranty: Lifetime warranty
