Περιγραφή
Design
LED indicators: Yes
Stackable: No
Rack mounting: No
Product colour: Black
Wall mountable: Yes
Power
Power source: DC
Input current: 1.25 A
DC input voltage: 54 V
Power consumption (max): 66.78 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 90%
Operating altitude: 0 - 3000 m
Heat dissipation: 228.38 BTU/h
Management features
Quality of Service (QoS) support: Yes
Switch type: Unmanaged
Weight & dimensions
Weight: 400 g
Depth: 101 mm
Width: 158 mm
Height: 27 mm
Network
Ethernet LAN data rates: 10,100,1000 Mbit/s
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u, IEEE 802.3i, IEEE 802.3x
10G support: No
Flow control support: Yes
Auto-sensing: Yes
Full duplex: Yes
Half duplex: Yes
Performance
Mean time between failures (MTBF): 4113947 h
Ports & interfaces
Power connector: DC-in jack
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Data transmission
Switching capacity: 10 Gbit/s
Packet buffer memory: 0.128 MB
Packet forwarding rate (1 Gbps): 1448000 pps
Jumbo frames support: Yes
Jumbo frames: 9216
MAC address table: 2000 entries
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 63 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE): Yes
Warranty: Manufacturer warranty 36 months
