Περιγραφή
CPU Support: Supports AMD Ryzen™ 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen™ 5 3400G & Ryzen™ 3 3200G) and AMD Ryzen™ 4000 G-Series desktop processors
Chipset: AMD B550
MB Size: microATX
Memory: 4 DIMM DDR4 Sockets for ECC & non-ECC un-buffered DDR4 RAM up to 3200+ MHz by JEDEC or up to 4400+ MHz by A-XMP OC MODE. Max 128GB. Dual Channel architecture
VGA: Supported only with CPUs with integrated AMD Radeon Vega Series Graphics
VGA Out: 1x D-Sub (supports resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz), 1x Display Port (max. resolution of 4096x2160 @60H, 1x HDMI (max. resolution of 4096x2160 @60Hz). Support DirectX 12
Slots: 1x PCIe (x16) v3.0/v4.0, 2x PCIe (x1) v3.0
Storage: 4x SATA3 6Gbps ports support RAID 0/1/10, 2x M.2 slots (Key M) support RAID 0/1, M2_1 slot (from AMD processor), Supports PCIe 4.0/3.0 x4, Supports SATA 6Gb/s, Supports 2242/ 2260/ 2280 storage devices, M2_2 slot (from AMD B550 chipset), Supports PCIe 3.0x4, Supports 2242/ 2260/ 2280 storage devices
NIC: 1x Realtek 8111HN Gigabit LAN controller
Audio: 7.1 Channel HD Audio
I/O: 1x PS/2 Keyb/Mouse combo port, 1x HDMI, 1x Display Port, 1x D-Sub, 2(+4int)x USB 2.0, 4(+2int) USB 3.2 Gen1, 1x RJ45 (LAN), 3 Audio jacks, 1x Front panel audio connector, 1x Clear CMOS jumper, Flash BIOS Button
Special: Core Boost, PCI-E Steel Armor, Mystic Light Extension, M.2 Shield Frozr, Lightning Gen4 Solution, Audio Boost, DDR4 Boost, 2oz Thickened Copper PCB
Εγγύηση: 3 χρόνια
