Processor
Supported processor sockets: Intel LGA1851
Maximum internal memory supported by processor: 256 GB
Processor socket: LGA 1851 (Socket V1)
Compatible processor series: Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Features
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 11
Motherboard chipset: Intel Z890
Product colour: Black
Motherboard chipset family: Intel
Audio chip: Realtek ALC897
Memory
Memory channels: Dual-channel
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Supported memory clock speeds: 6400, 8800 MHz, 4800
Supported memory clock speed (max): 8800 MHz
ECC ?ompatibility: Non-ECC
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Bluetooth version: 5.4
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: Yes
Wi-Fi standards: IEEE 802.11ac, IEEE 802.11n, IEEE 802.11ax, Wi-Fi 7 (802.11be), 802.11g, 802.11b, 802.11a
Internal I/O
EPS power connector (8-pin): Yes
USB 2.0 connectors: 4
Number of SATA III connectors: 4
ATX Power connector (24-pin): Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of EPS power connectors (8-pin): 1
Total number of SATA connectors: 4
Storage controllers
Supported storage drive interfaces: M.2, SATA III
RAID levels: 10, 1, 0, 5
Supported storage drive types: HDD & SSD
RAID support: Yes
Rear panel I/O ports
DisplayPort version: 1.4
DisplayPorts quantity: 1
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
HDMI ports quantity: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Thunderbolt ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 3
PCI Express x16 slots: 4
Warranty: warranty 36 months
