Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Maximum internal memory supported by processor: 256 GB
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Features
Audio output channels: 7.1 channels
Product colour: Black
Audio chip: Realtek ALC897
Motherboard form factor: ATX
Motherboard chipset: AMD B850
Windows operating systems supported: Windows 11 x64
Motherboard chipset family: AMD
Memory
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Supported memory clock speeds: 6000, 4800, 8200, 6400, 5600 MHz
ECC ?ompatibility: Non-ECC
Maximum internal memory: 256 GB
Supported memory clock speed (max): 8200 MHz
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Ethernet LAN: Yes
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), 802.11n, 802.11g, 802.11b
Bluetooth version: 5.3
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth: Yes
Internal I/O
RGB LED pin header: Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Number of SATA III connectors: 4
CPU fan connector: Yes
TPM connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 2.0 connectors: 4
Storage controllers
Number of HDDs supported: 4
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
RAID levels: 1, 0, 10
RAID support: Yes
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
DisplayPort version: 1.4
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
DisplayPorts quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
Number of M.2 (M) slots: 2
2nd M.2 largest key size: 2280
1st M.2 largest key size: 22110
Warranty: warranty 36 months
