Περιγραφή
Processor
Compatible processor series: AMD Ryzen(TM) 4000 G-Series, AMD Ryzen 5000 Series, AMD Ryzen 3000 Series
Processor manufacturer: AMD
Supported processor sockets: Socket AM4
Processor socket: Socket AM4
Features
Motherboard chipset family: AMD
Audio output channels: 7.1 channels
Motherboard chipset: AMD B550
Audio chip: Realtek ALC897
Memory
Memory slots type: DIMM
Number of memory slots: 4000
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
Maximum internal memory: 128 GB
Supported memory clock speed (max): 4800 MHz
Unbuffered memory: Yes
ECC ?ompatibility: Non-ECC
Supported memory clock speeds: 3200, 4266, 3466, 4866 MHz, 4600, 3866, 4533, 3000, 2800, 4133, 4000, 4800, 2933, 3600, 4733, 2667, 3733, 4400, 3066
Weight & dimensions
Width: 243.8 mm
Depth: 304.8 mm
Network
Bluetooth version: 5.3
Ethernet interface type: Gigabit Ethernet
Wi-Fi standards: Wi-Fi 6 (802.11ax)
Ethernet LAN: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Bluetooth: Yes
LAN controller: Realtek 8111H
Internal I/O
RGB LED pin header: Yes
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 6
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
Total number of SATA connectors: 6
Number of SATA connectors: 6
CPU fan connector: Yes
TPM connector: Yes
Front panel connector: Yes
USB 2.0 connectors: 4
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 3.0, SATA
Number of storage drives supported: 8
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
HDMI version: 1.4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
HDMI ports quantity: 1
DisplayPort version: 1.2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 2
1st M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 3.0
2nd M.2 largest key size: 2280
1st M.2 largest key size: 22110
PCI Express x16 slots: 2
Warranty: warranty 36 months
