MSI Mb Pro B760-P II, Socket LGA1700 14th/13th/12th Gen CPU, Cs Intel B760, 4 Dimm Sockets DDR5 HDMI/DP, PCI-E Gen 4.0, 2.5G LAN, ATX, 3YW. - (911-7E29-009)

CPU Support: LGA 1700, supports Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors
Chipset: INTEL B760.
MB Size: ATX.
Memory Support: 4 DIMM DDR5 Sockets for non-ECC un-buffered DDR5 RAM up to 7000+ MT/s (OC) or up to 5600 MT/s JEDEC. Max 256GB. Support Dual-Controller Dual Channel mode. Support Intel XMP 3.0. (OC)
VGA Out: (Availiable only on processors featuring integrated GPU)

1x HDMI 2.1 maximum resolution of 4K 60Hz.
1x DisplayPort 1.4 maximum resolution of 4K 60Hz.
Slots: 5x PCI-E (x16) slots:

PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU).
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset).
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset).
PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset).
PCI_E5 Gen PCIe 3.0 supports up to x1 (From Chipset).
Storage:

2x M.2:

M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260/2242 devices.
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260/2242 devices.
4x SATA 6G.
RAID: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices.
LAN: Realtek RTL8125GB 2.5G LAN.
Audio: Realtek ALC897 Codec 7.1-Channel High Definition Audio. Supports S/PDIF output.
I/O:

2x USB 2.0 (Rear).
4x USB 2.0 (Front).
2x USB 5Gbps Type A (Rear).
4x USB 5Gbps Type A (Front).
1x USB 5Gbps Type C (Front).
1x USB 10Gbps Type C (Rear).
1x 2.5G LAN (Rear).
1x DisplayPort (Rear).
1x HDMI (Rear).
Audio Connectors (Rear).
S/PDIF-OUT (Rear).
Special Features: 2.5G Network Solution, M.2 Shield Frozr, EZ Debug LED, Latest DDR5 Memory, Lightning Gen4 Solution, Extended Heatsink Design, Frozr AI Cooling, Memory boost, Core boost.
Εγγύηση: 3 έτη.
