Processor
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series
Maximum internal memory supported by processor: 256 GB
Processor socket: Socket AM5
Graphics
On-board graphics card: No
Features
Motherboard form factor: ATX
PC health monitoring: Temperature, CPU, Voltage, Fan
Audio output channels: 7.1 channels
Motherboard chipset: AMD X870
Motherboard chipset family: AMD
Memory
ECC ?ompatibility: Non-ECC
Supported memory clock speeds: 4800, 6000, 5200, 8000, 5800, 5400, 7000, 8200 MHz, 6600, 7600, 7800, 6800, 6400, 6200, 7400, 5600, 7200 MHz, 5000
Maximum internal memory: 256 GB
Number of memory slots: 4
Memory slots type: DIMM
Memory channels: Dual-channel
Supported memory clock speed (max): 8200+ MHz
Supported memory types: DDR5 DIMM
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
LAN controller: Realtek RTL8126
Bluetooth: Yes
Wi-Fi standards: 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Wi-Fi: Yes
Ethernet LAN: Yes
Bluetooth version: 5.4
Ethernet interface type: 5 Gigabit Ethernet
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 6
Number of SATA III connectors: 4
EPS power connector (8-pin): Yes
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
USB 2.0 connectors: 10
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 2
Total number of SATA connectors: 4
Storage controllers
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 7
Number of HDDs supported: 4
Rear panel I/O ports
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
S/PDIF out port: No
DisplayPort version: 1.4
USB4 Gen 2x2 ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Microphone in: Yes
HDMI ports quantity: 1
Expansion slots
3rd M.2 largest key size: 2280
3rd M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
2nd M.2 largest key size: 22110
1st M.2 largest key size: 2280
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty.
Warranty: warranty 36 months
