Περιγραφή
Processor
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Processor socket: Socket AM5
Features
Audio output channels: 7.1 channels
Product colour: Black
Audio chip: Realtek ALC897
Motherboard chipset: AMD B840
Windows operating systems supported: Windows 11 x64
Motherboard chipset family: AMD
Motherboard form factor: ATX
Memory
Supported memory clock speed (max): 8000 MHz
Supported memory clock speeds: 6400 MHz, 4800, 8000, 5600
Maximum internal memory: 256 GB
ECC ?ompatibility: Non-ECC
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Memory channels: Dual-channel
Weight & dimensions
Depth: 304.8 mm
Width: 243.8 mm
Network
Bluetooth: Yes
Bluetooth version: 5.3
Wi-Fi standards: 802.11g, 802.11b, IEEE 802.11ac, IEEE 802.11n, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax)
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Internal I/O
RGB LED pin header: Yes
Number of RGB LED pin headers: 4
Number of CPU fan connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
Number of SATA III connectors: 4
USB 2.0 connectors: 4
Total number of SATA connectors: 4
Storage controllers
Supported storage drive interfaces: M.2, Micro SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
Number of HDDs supported: 4
RAID levels: 10, 1, 0
Number of storage drives supported: 7
Rear panel I/O ports
HDMI version: 2.1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots
3rd M.2 largest key size: 2280
3rd M.2 highest PCI Express generation: 3.0
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 22110
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 3.x) slots: 1
Number of M.2 (M) slots: 3
Warranty: warranty 36 months
