Characteristics
o 16 channel, 160 Mbps, Dual stream
o 16x10/100 PoE ports
o Linux OS embedded for stability
o High profile H.265/H.264 coding and decoding
o Ultra high definition 3840*2160 resolution
o Support HDMI and VGA
o Support 32-ch network cameras with up to 720P resolution
o Up to 2 SATA interfaces, up to 10TB capability for each SATA
o Multiple-level users
o Friendly GUI for configuration
Specifications
Input
Network Video Input
16-CH
Bandwidth Requirement
80Mbps (Incoming)50Mbps (Outgoing)
Output
HDMI Output
1-CH, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz. (HDMI supports Audio Output)
VGA Output
1-CH, Resolution: 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz.
Dual Stream
Support
Recording Resolution
8MP/6MP/5MP/4MP/3MP/1080P/ UXGA/720P/D1/VGA/CIF/QCIF
Synchronous Playback
1*(30fps @8MP), 2*(30fps @6MP), 2*(30fps @5MP), 3*(30fps @4MP), 4*(30fps @3MP), 6*(30fps @1080P), 12*(30fps @720P)
Format
Video Compression
H.265+/H.265(HEVC)/H.264+/H.264
Audio Format
G.711/AAC/G.722/G.726
Storage
SATA
2*SATA HDD (3.5")
Capacity
Up to 10TB capacity for each HDD
Record
Recording Type
Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)
Snapshot Type
Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)
Playback Type
General Playback, Event Playback, Tag Playback, Split Playback, Picture Playback
Backup
Video backup, Image Backup
Network
Network Protocols
IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS
Interface
Network Interface
1*RJ45 10/100/1000Mbps
USB Interface
2*USB 2.0
Audio Input/Output
1*RCA/1*RCA
Alarm Input/Output
4-CH/1-CH
PoE Interface
Interface
16*RJ45 10/100Mbps
Power Output
<=200W
Supported Standard
IEEE 802.3af/at
General
Compatibility
ONVIF, API
Advanced Function
ANR
ANPR
Support
Video Analysis
Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting
Keyboard Control
Milesight Keyboard(MS-K01)
Power Supply
AC 100V~240V 50Hz~60Hz
Consumption
<=8.5W(Without HDD, without enabling PoE)
Working Conditions
Temperature: -10°C~+55°C / Humidity: 10%~90%
Dimensions
380mm(W)X317.6mm(D)X51.8mm(H), Rack Mountable Chassis(1.0U Standard)
Weight
2.7Kg
