Specifications
Input
Network Video Input
8-CH
Bandwidth Requirement
80Mbps (Incoming)80Mbps (Outgoing)
Output
HDMI Output
1-CH, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz. (HDMI supports Audio Output)
Dual Stream
Recording Resolution
Synchronous Playback
Format
Video Compression
H.265+/H.265(HEVC)/H.264+/H.264
Audio Format
G.711/AAC/G.722/G.726
Storage
SATA
1*SATA HDD (3.5")
Capacity
Up to 10TB capacity for each HDD
Record
Recording Type
Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)
Playback Type
General Playback, Event Playback, Tag Playback, Split Playback, Picture Playback
Backup
Video backup, Image Backup
Network
Network Protocols
IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS
Interface
Network Interface
1*RJ45 10/100Mbps
USB Interface
2*USB 2.0
PoE Interface
Interface
4*RJ45 10/100Mbps
Power Output
<=40W
Supported Standard
IEEE 802.3af/at
General
Compatibility
ONVIF, API
Advanced Function
ANR
Video Analysis
Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting, Object Left, Object Removed
Keyboard Control
Milesight Keyboard(MS-K01)
Power Supply
DC 48V 1.3A
Consumption
<=3.5W(Without HDD, without enabling PoE)
Working Conditions
Temperature: -10?~+55? / Humidity: 10%~90%
Dimensions
220mm(W)X200mm(D)X43.6mm(H)
Weight
0.2Kg
