Support PoE; Built-in Microphone; SD card, up to 256G; 3-Axis Design
Support H.265+/H.265/H.264+/H.264
AI based Video Content Analysis, People Counting
Specifications
Camera
Image Sensor
1/2.8? Progressive Scan CMOS
Min. Illumination
Color:
[email protected] Color:
[email protected] B/W: 0Lux with IR on
WDR
120dB Super WDR
Shutter Time
1/100000s~1s
IR Distance
Up to 50m
Day/Night Mode
Day/Night/Auto/Customize/Schedule
S/N
>55dB
Lens Lens
Motorized 2.7~13.5mm/3.0~10.5mm/
[email protected] P-Iris(Optional)
Field of View
H99°~H31°/ D124°~D38°/V72°~V23° (2.7~13.5mm) H89°~H31°/D111°~D38°/V66°~V23° (3.0~10.5mm) H37°~H15°/D46°~D19°/V28°~V11° (7~22mm)
Mount
Φ14
Focus Control
Auto/Manual
Iris Control
N/A
Video
Max. Image Resolution
2592x1944
Primary Stream
60Hz: 30fps@(2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576) 50Hz: 25fps@(2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576)
Secondary Stream
60Hz: 30fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192)50Hz: 25fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192)
Tertiary Stream
60Hz: 30fps@(1280x720, 704x576, 640x480, 640x360, 352x288, 320x240, 320x192) 50Hz: 25fps@(1280x720, 704x576, 640x480, 640x360, 352x288, 320x240, 320x192)
Video Compression
H.265 +/H.265(HEVC)/H.264 +/H.264/MJPEG
Video Bit Rate
16Kbps~16Mbps(CBR/VBR Adjustable)
Privacy Masking
Up to 24 areas
ROI
Up to 8 areas
Image Setting
Brightness/Contrast/Saturation/Sharpness
Interface
Ethernet
1*RJ45 10M/100M Ethernet Port
Audio I/O
1/1 (Multi-interface Version)
Alarm I/O
1/1 (Multi-interface Version)
Network Network Storage
NAS(Support NFS, SMB/CIFS), ANR
Protocol
IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP,UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL
Audio
Audio Compression
G.711/AAC/G.722/G.726
Audio Sampling Rate
8/16/32/44.1/48KHz
Audio Bit Rate
16~256kbps
Two-way Audio
Support
Intelligent Analytics
Video Analysis
Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed
People Counting&Report
Count the number of people entering or exiting, up to 4 detection areas for regional people counting
System Storage
Support microSD/SDHC/SDXC Card Local Storage, up to 256G
Advanced Function
BLC, HLC, 2D DNR, 3D DNR, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark
SIP/VoIP Support
Yes, Voice & Video-over-IP
Event Trigger
Motion Detection, Network Disconnection, etc
Event Action
FTP Upload, SMTP Upload, SD Card Record, SIP Phone, HTTP Notification, etc.
System Compatibility
ONVIF Profile G & Q & S & T, API
General Working Temperature
-40°C~60°C
Working Humidity
0~90%(Non-condensing)
Power Supply
PoE (802.3af) / DC 12V±10%
Power Consumption
8.5W MAX 11W MAX (With IR on)
Housing
Vandal-proof IK10-rated Metal Housing / Up to IP67-rated for Weather-resistant Performance
Weight
825g
Dimensions
Φ76mmX239.5mm
Warranty
3/5 Years
