Description
8-channel, 8 MP, 80 Mbps
o Noise-free and energy-saving intelligent fan
o Easy to install
o Friendly GUI for configuration
o High profile H.265/H.264 coding and decoding
o Full support 1*HDD(3.5") max, 10TB
o Support up to 8 IP Cameras
o DDNS for remote connection
o Multiple-level users
o Dual stream
o Ultra high definition 3840*2160 resolution
o Support HDMI port
Specifications
Video/Audio Input Network Video Input
8-CH
Incoming Bandwidth
80Mbps
Outgoing Bandwidth
80Mbps
Video/Audio Output HDMI Output
1-CH, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI Supports Audio Output
Dual Stream
Support
Recording Resolution
8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/D1/VGA/CIF/QCIF
Synchronous Playback
1*(30fps @8MP), 1*(30fps @6MP), 1*(30fps @5MP), 2*(30fps @4MP), 2*(30fps @3MP), 4*(30fps@1080P), 8*(30fps @720P)
Video/Audio Compression Video Compression
H.265 +/H.265(HEVC)/H.264 +/H.264
Audio Compression
G.711/AAC/G.722/G.726
Sample Rate
8KHz/16KHz
Synchronous Recording
8*5MP
Storage SATA
1*SATA HDD(3.5")
Capacity
Up to 10TB capacity for each HDD
Recording Management Recording Type
Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)
Snapshot Type
N/A
Playback Type
Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)
Backup
Backup
Video Backup, Image Backup
Network
Protocol
IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP,
External Interface Network Interface
1*RJ45 10/100Mbps
USB Interface
2*USB 2.0
General Compatibility
ONVIF, API
Advanced Function
ANR
ANPR
N/A
Video Analysis
Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting, Object Left, Object Removed
Keyboard Control
Milesight Keyboard (MS-K01)
Power Supply
DC 12V 2A
Consumption
<=2.3W(Without HDD)
Working Conditions
Temperature: -10°C~55°C/Humidity: 10%~90%
Dimensions
220mm(W)X200mm(D)X43.6mm(H)
Weight
0.19Kg
