Features
4-channel, 8 MP, 40 Mbps
o 4 x 10/100PoE ports
o Noise-free and energy-saving intelligent fan
o Easy to install
o Friendly GUI for configuration
o High profile H.265+/H.264 coding and decoding
o Full support 1*HDD(3.5") max, 10TB
o Support up to 4 IP Cameras
o DDNS for remote connection
o Multiple-level users
o Dual stream
o Ultra high definition 3840*2160 resolution
o Support HDMI port
Specifications
Video/Audio Input Network Video Input
4-CH
Incoming Bandwidth
40Mbps
Outgoing Bandwidth
40Mbps
Video/Audio Output HDMI Output
1-CH, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60H, 1280x720/60Hz, 1024x768/60Hz HDMI Supports Audio Output
Dual Stream Support
Yes
Recording Resolution
8MP/6MP/5MP/4MP/3MP/1080P/
UXGA/720P/D1/VGA/CIF/QCIF
Synchronous Playback
1*(30fps @8MP), 1*(30fps @6MP), 1*(30fps @5MP), 2*(30fps @4MP), 2*(30fps @3MP), 4*(30fps @1080P), 4*(30fps @720P)
Video/Audio Compression Video Compression
H.265 +/H.265(HEVC)/H.264 +/H.264
Audio Compression
G.711/AAC/G.722/G.726
Sample Rate
8KHz/16KHz
Synchronous Recording
4*5MP
Storage SATA
1*SATA HDD(3.5")
Capacity
Up to 10TB capacity for each HDD
Recording Management Recording Type
Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)
Snapshot Type
Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis)
Playback Type
General Playback, Event Playback, Tag Playback, Split Playback, Picture Playback
Backup
Backup
Video Backup, Image Backup
Network
Protocol
IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS
External Interface Network Interface
1*RJ45 10/100Mbps
USB Interface
2*USB 2.0
PoE Interface Interface
4*RJ45 10/100Mbps
Power Output
<=40W
Supported Standard
IEEE 802.3af/at
General Compatibility
ONVIF
Advanced Function
ANR
Video Analysis
Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting, Object Left, Object Removed
Keyboard Control
Milesight Keyboard (MS-K01)
Power Supply
DC 48V 1.3A
Consumption
<=3.5W(Without HDD, without enabling PoE )
Working Conditions
Temperature: -10°C~55°C/Humidity: 10%~90%
Dimensions
220mm(W)X200mm(D)X43.6mm(H)
Weight
0.2Kg
