This switch is an indoor variation of the prominent netFiber 9 switch - used by many small and medium ISPs for reliable 10 Gigabit fibre connections stretching over a 100 meters. With five 1G SFP ports, four 10G SFP+ ports, and an additional Gigabit Ethernet port, this is the perfect upgrade for existing CRS212 setups. You’re getting the modern ARM v7 CPU, 256 MB of RAM, and better cooling. The new Marvell switch-chips bring phenomenal performance to the table!
The Gigabit Ethernet port has a direct connection to the switch chip - so you can enjoy full gigabit speed there. And it supports PoE-in, giving you an additional powering option in tricky spots.
You can mount this switch in a standard 1U rack to keep everything organized. And it has all the power you would expect from a rackmount device: CRS310 supports hardware offloaded VLAN- filtering. And even some hardware offloaded Layer-3 routing.
Specifications
Details
Product code
CRS310-1G-5S-4S+IN
Architecture
ARM 32bit
CPU
98DX226S
CPU core count
1
CPU nominal frequency
800 MHz
Switch chip model
98DX226S
Dimensions
200 x 166 x 45 mm
RouterOS license
5
Operating System
RouterOS
Size of RAM
256 MB
Storage size
16 MB
Storage type
FLASH
MTBF
Approximately 200’000 hours at 25C
Tested ambient temperature
-40°C to 70°C
Suggested price
Powering
Number of DC inputs
2 (DC jack, PoE-IN)
DC jack input Voltage
18-57 V
Max power consumption
20 W
Max power consumption without attachments
8 W
Cooling type
1 fan
PoE in
802.3af/at
PoE in input Voltage
18-57 V
Ethernet
10/100/1000 Ethernet ports
1
Fiber
SFP ports
5
SFP+ ports
4
Peripherals
Serial console port
RJ45
Other
CPU temperature monitor
Yes
PCB temperature monitor
Yes
Voltage Monitor
Yes
Certifications
Certification
CE, EAC, ROHS
IP
20
