Περιγραφή
Design
Mounting type: Ceiling
Form factor: Tube/dome
International Protection (IP) code: IP66
Product colour: White
Housing material: Metal, Plastic
Power
DC output voltage: 12
Power source type: DC, PoE
Power consumption (max): 6.2 W
Operational conditions
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -20 - 50 °C
Storage temperature (T-T): -20 - 50 °C
Management features
Web browser: Yes
Web-based management: Yes
Weight & dimensions
Height: 144 mm
Weight: 390 g
Depth: 110 mm
Width: 136 mm
Network
Number of users: 20 user(s)
Bluetooth: No
Networking standards: IEEE 802.11g, IEEE 802.11n, IEEE 802.11b
Ethernet interface type: 100 Megabit Ethernet
Wi-Fi: Yes
System requirements
Mobile operating systems supported: Android, iOS
Performance
Placement supported: External / Internal
Type: IP security camera
Connectivity technology: Wired
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Storage
Built-in HDD: No
Camera
Horizontal rotation angle: 0 - 355°
Vertical rotation angle: 0 - 90°
Diagonal angle of view (max): 94°
Adjustment shutter speed: Auto/Manual
Lens viewing angle, vertical: 44°
Lens viewing angle, horizontal: 79°
Image sensor
Number of sensors: 1
Sensor type: CMOS
Progressive scan: Yes
Optical sensor size: 25.4 / 3 mm (1 / 3")
Video
Video compression formats: H.264, H.265
Video streaming: Yes
Gain control type: Auto/Manual
Maximum resolution: 2560 x 1440 pixels
Total megapixels: 4 MP
Frame rate: 25 / 30 fps
Digital zoom: 16x
Noise reduction: Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Night vision
Night vision: Yes
Number of illumination LEDs: 2
Night vision distance: 30 m
LED type: IR
Lens system
Number of lenses: 1
Lens type: Fixed focal length lens
Maximum aperture number: 1
Focal length range: 3.6 mm
Safety warning
Warnings: The product contains electronic components; do not dispose of with the normal household waste., Avoid direct contact with water to prevent electrical damage., Ensure that the product is properly installed and protected against falling.
Warranty: Manufacturer warranty 24 months
