Περιγραφή
Design
Housing material: Plastic, Metal
IK code: IK08
International Protection (IP) code: IP67
Form factor: Dome
Product colour: White
Mounting type: Ceiling
Power
Power consumption (max): 6 W
DC output current: 0.5 A
Power consumption (Power over Ethernet (PoE)): 7.5 W
Power source type: DC, PoE
DC output voltage: 12
Security
Video motion detection: Yes
Password protection: Yes
Mirror: Yes
Heartbeat: Yes
HTTPS encryption: Yes
Password reset via email: Yes
Operational conditions
Operating temperature (T-T): -30 - 60 °C
Storage temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Weight & dimensions
Weight: 550 g
Height: 97.6 mm
Diameter: 12.1 cm
Network
Ethernet interface type: Fast Ethernet
Bluetooth: No
Wi-Fi: No
Networking standards: IEEE 802.3af
Ethernet LAN: Yes
Supported network protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
Number of simultaneous live view channels: 6 channels
Number of users: 32 user(s)
Live view: Yes
User access level: Administrator, Operator, User
Performance
Built-in light: Yes
Dynamic range: 120 dB
Wide Dynamic Range (WDR): Yes
Infrared (IR) cut-off filter: Yes
Languages support: Polish
Connectivity technology: Wired
Placement supported: Indoor & outdoor
Type: IP security camera
Number of languages: 1
Day/night mode: Yes
Packaging data
Package weight: 800 g
Package depth: 150 mm
Package width: 150 mm
Package height: 141 mm
Packaging content
Number of cameras: 1
Manual: Yes
Mounting kit: Yes
Audio
Built-in microphone: Yes
Sample rates: 8 - 16 kHz
Bit rate range: 16 - 160 Kbit/s
Signal-to-Noise Ratio (SNR): 52 dB
Audio formats supported: G.711 A-law, MP2L2, G.722.1, AAC-LC, G.711 μ-law, PCM
Storage
Built-in HDD: No
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Tilt angle range: 0 - 75°
Number of Privacy masking areas: 4
Minimum illumination: 0 lx
Lens viewing angle, horizontal: 105°
Lens viewing angle, diagonal: 127°
Lens viewing angle, vertical: 55°
Pan range: 0 - 355°
Camera shutter speed: 1/100000 - 1/3 s
Angle of rotation: 355°
Image sensor
Number of sensors: 1
Optical sensor size: 25.4 / 2.4 mm (1 / 2.4")
Progressive scan: Yes
Sensor type: CMOS
Video
Supported graphics resolutions: 1920 x 1080 (HD 1080), 640 x 360, 2560 x 1440, 640 x 480 (VGA), 3200 x 1800, 1280 x 720 (HD 720)
Back Light Compensation (BLC): Yes
Privacy masking: Yes
Image quality adjustment: Brightness, Contrast, Sharpness, Saturation
Maximum resolution: 3200 x 1800 pixels
Video recording: Yes
Video formats supported: H.264, H.264+, H.265+, H.265
Video compression formats: H.264+, H.264, H.265+, H.265
Supported video modes: 360p, 480p, 1080p, 720p, 1440p
Digital Wide Dynamic Range (DWDR): Yes
Highlight Compensation (HLC): Yes
Total megapixels: 6 MP
Noise reduction: Yes
Frame rate: 20 fps
Noise reduction technology: 3D noise reduction
Night vision
LED type: IR/White
Infra-red wavelength: 850 nm
Night vision distance: 30 m
Night vision: Yes
Lens system
Identify distance: 7 m
Number of lenses: 1
Fixed focal length: 2.8 mm
Recognize distance: 15 m
Maximum aperture number: 1.6
Detect distance: 76 m
Observe distance: 30 m
Sustainability
Compliance certificates: REACH, WEEE, BIS, RoHS, CE, UL, CB
Sustainability compliance: Yes
Warranty: Manufacturer warranty 24 months
