Hikvision Pro Series with AcuSense Bullet IP security camera Outdoor 3840 x 2160 pixels Ceiling/wall - (DS-2CD2186G2H-ISU(2.8mm)(eF))

Technical details
Lens mount interface: M12

Design
Mounting type: Ceiling/wall
Product colour: White
Protection features: Water resistant, Dust resistant
Form factor: Bullet
Housing material: Aluminium
International Protection (IP) code: IP67
IK code: IK10

Power
Power consumption (Power over Ethernet (PoE)): 9.5 W
DC output current: 0.66 A
DC output voltage: 12
Power source type: DC, PoE
Power consumption (max): 8 W

Security
Network access storage (NAS): Yes
Automatic Network Replenishment (ANR): Yes
Flash log: Yes
Audit log: Yes
Digital watermark: Yes
Alarm input channels: 1
Heartbeat: Yes
Video motion detection: Yes
Privacy protection: Yes
Alarm output channels: 1
Password protection: Yes
Active tampering alarm: Yes
Mirror: Yes
Intelligent Video Surveillance (IVS) system features: Face detection
HTTPS encryption: Yes
IP address filtering: Yes
Security algorithms: HTTPS, TLS
Digest authentication: Yes
Pixel counter: Yes
Password reset via email: Yes
Human and vehicle targets classification: Yes

Operational conditions
Storage temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -30 - 60 °C
Operating relative humidity (H-H): 0 - 95%

Management features
Behavior analysis: Intrusion detection, Line crossing detection
Web-based management: Yes
Reset button: Yes

Weight & dimensions
Weight: 525 g
Diameter: 12.2 cm
Height: 97.6 mm

Network
Live view: Yes
Client interoperability: iVMS-4200, Hik-Connect, Hik-Central
Number of users: 32 user(s)
Networking standards: IEEE 802.1x, IEEE 802.3af
Bluetooth: No
Number of simultaneous live view channels: 6 channels
User access level: Administrator, Operator, User
Ethernet interface type: Fast Ethernet
Quality of Service (QoS) support: Yes
Ethernet LAN: Yes
Wi-Fi: No

Performance
Infrared (IR) cut-off filter: Yes
Languages support: Multi
Dynamic range: 130 dB
Number of languages: 33
Alarm input/output: Yes
Day/night mode: Yes
Placement supported: Outdoor
Connectivity technology: Wired
Wide Dynamic Range (WDR): Yes
Type: IP security camera

Packaging data
Package depth: 120 mm
Package weight: 750 g
Package width: 234 mm
Package height: 117 mm

Packaging content
Number of cameras: 1

Audio
Audio formats supported: G.711 μ-law, G.711 A-law, MP2L2, AAC-LC, PCM, G.726, MP3, G.722.1
Signal-to-Noise Ratio (SNR): 52 dB
Audio output channels: 1.0 channels
Built-in microphone: Yes
Sample rates: 8 - 48 kHz
Bit rate range: 8 - 320 Kbit/s
Audio input channels: 1.0 channels

Storage
Maximum memory card size: 512 GB
Built-in HDD: No
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Card reader integrated: Yes

Ports & interfaces
Terminal block port: Yes
Ethernet LAN (RJ-45) ports: 1

Camera
Number of Privacy masking areas: 4
Tilt angle range: 0 - 75°
Lens viewing angle, horizontal: 105.1°
Lens viewing angle, diagonal: 128.2°
Minimum illumination: 0 lx
Angle of rotation: 355°
Camera shutter speed: 1/3 - 1/100000 s
Lens viewing angle, vertical: 54.8°
Pan range: 0 - 355°

Other features
Browser supported: IE 10, IE 11, Chrome 57.0+, Firefox 52.0+

Image sensor
Number of sensors: 1
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
Progressive scan: Yes
Sensor type: CMOS

Video
Noise reduction: Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Privacy masking: Yes
Image quality adjustment: Saturation, Sharpness, Contrast, Brightness
Region of Interest (ROI) encoding: Yes
Frame rate: 30 fps
Noise reduction technology: 3D noise reduction
Video compression formats: H.264, H.265+, H.265, H.264+, M-JPEG
Video streaming: Yes
Supported graphics resolutions: 640 x 480 (VGA), 1280 x 720 (HD 720), 640 x 360, 3840 x 2160, 2688 x 1520, 1920 x 1080 (HD 1080), 3200 x 1800
Maximum resolution: 3840 x 2160 pixels
Bit rate: 32 Kbps - 16 Mbps
Total megapixels: 8 MP
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes

Night vision
Infra-red wavelength: 850 nm
Night vision: Yes
LED type: IR
Night vision distance: 30 m

Lens system
Number of lenses: 1
Observe distance: 35 m
Recognize distance: 17 m
Maximum aperture number: 1
Identify distance: 8 m
Fixed focal length: 2.8 mm
Detect distance: 89 m

Sustainability
Compliance certificates: RoHS, CE, Low Voltage Directive (LVD), CB, UL


Warranty: Manufacturer warranty 24 months
