Technical details
Lens mount interface: M12
Design
Product colour: White, Black
Form factor: Bullet
Mounting type: Ceiling/wall
Housing material: Metal
International Protection (IP) code: IP67
Protection features: Water resistant
Power
Power source type: DC, PoE
Power consumption (Power over Ethernet (PoE)): 7 W
DC output current: 0.45 A
DC output voltage: 12
Power consumption (max): 5.5 W
Security
Pixel counter: Yes
Password reset via email: Yes
Flash log: Yes
Automatic Network Replenishment (ANR): Yes
Audit log: Yes
Network access storage (NAS): Yes
Security algorithms: HTTPS, TLS
Mirror: Yes
Active tampering alarm: Yes
Heartbeat: Yes
Privacy protection: Yes
Human and vehicle targets classification: Yes
IP address filtering: Yes
Intelligent Video Surveillance (IVS) system features: Face detection
HTTPS encryption: Yes
Digest authentication: Yes
Password protection: Yes
Video motion detection: Yes
Operational conditions
Storage temperature (T-T): -30 - 60 °C
Operating temperature (T-T): -30 - 60 °C
Storage relative humidity (H-H): 0 - 95%
Operating relative humidity (H-H): 0 - 95%
Management features
Reset button: Yes
Web-based management: Yes
Behavior analysis: Intrusion detection, Line crossing detection
Weight & dimensions
Weight: 525 g
Length: 179.2 mm
Diameter: 7.44 cm
Network
Number of simultaneous live view channels: 6 channels
User access level: Administrator, Operator, User
Bluetooth: No
Networking standards: IEEE 802.3af, IEEE 802.1x
Live view: Yes
Client interoperability: iVMS-4200, Hik-Connect, Hik-Central
Number of users: 32 user(s)
Quality of Service (QoS) support: Yes
Wi-Fi: No
Ethernet interface type: Fast Ethernet
Ethernet LAN: Yes
Performance
Connectivity technology: Wired
Infrared (IR) cut-off filter: Yes
Languages support: Multi
Dynamic range: 120 dB
Number of languages: 33
Placement supported: Outdoor
Day/night mode: Yes
Type: IP security camera
Wide Dynamic Range (WDR): Yes
Packaging data
Package weight: 750 g
Package width: 234 mm
Package height: 117 mm
Package depth: 120 mm
Packaging content
Number of cameras: 1
Audio
Built-in microphone: Yes
Bit rate range: 8 - 320 Kbit/s
Sample rates: 8 - 48 kHz
Signal-to-Noise Ratio (SNR): 52 dB
Audio formats supported: G.711 μ-law, G.711 A-law, MP3, G.722.1, AAC-LC, G.726, PCM, MP2L2
Storage
Built-in HDD: No
Maximum memory card size: 512 GB
Card reader integrated: Yes
Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
Camera
Number of Privacy masking areas: 4
Tilt angle range: 0 - 90°
Lens viewing angle, vertical: 54.7°
Lens viewing angle, diagonal: 119.7°
Lens viewing angle, horizontal: 100.2°
Camera shutter speed: 1/3 - 1/100000 s
Pan range: 0 - 360°
Minimum illumination: 0 lx
Angle of rotation: 360°
Other features
Browser supported: IE 10, IE 11, Chrome 57.0+, Firefox 52.0+
Image sensor
Sensor type: CMOS
Progressive scan: Yes
Number of sensors: 1
Optical sensor size: 25.4 / 3 mm (1 / 3")
Video
Supported graphics resolutions: 640 x 480 (VGA), 2688 x 1520, 1920 x 1080 (HD 1080), 1280 x 720 (HD 720), 640 x 360
Maximum resolution: 2688 x 1520 pixels
Smart IR: Yes
Video compression formats: H.264+, H.265+, H.265, M-JPEG, H.264
Image quality adjustment: Sharpness, Saturation, Contrast, Brightness
Region of Interest (ROI) encoding: Yes
Noise reduction technology: 3D noise reduction
Video streaming: Yes
Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Noise reduction: Yes
Privacy masking: Yes
Total megapixels: 4 MP
Frame rate: 30 fps
Bit rate: 32 Kbps - 8192 Kbps
Back Light Compensation (BLC): Yes
Highlight Compensation (HLC): Yes
Night vision
Infra-red wavelength: 850 nm
Night vision: Yes
LED type: IR
Night vision distance: 40 m
Lens system
Number of lenses: 1
Maximum aperture number: 1
Observe distance: 25 m
Recognize distance: 12 m
Fixed focal length: 2.8 mm
Detect distance: 63 m
Identify distance: 6 m
Sustainability
Compliance certificates: Low Voltage Directive (LVD), CB, RoHS, CE, UL
Warranty: Manufacturer warranty 36 months
